Product Details

Precision Machinery for Grain Bin & Silo Corrugated Panel and Sidewall Production

In the world of agricultural bulk storage, the strength and integrity of a grain bin or silo depend on the quality of its corrugated panels and sidewalls. BenThomas is a trusted global manufacturer providing specialized fabrication machinery engineered to produce these critical components with unmatched precision and efficiency. We offer targeted solutions, from standalone machines to fully integrated lines, empowering manufacturers to build durable and reliable storage systems.

High-Precision Forming and Bending Solutions

At the core of sidewall production is the grain bin silo sidewall roll bending machine. This robust equipment is designed to consistently form the curved side body sections of bins and silos, ensuring accurate radii and a perfect fit during assembly. For the essential corrugated sheets, our grain bin silo corrugated panel production machine delivers uniform, high-strength panels in continuous lengths. Similarly, our dedicated silo corrugated panel production machine is optimized for the specific profiles and material grades required in large-scale commercial silos.

Whether you are fabricating panels for farm bins or industrial silos, BenThomas has the right equipment. Our grain bin corrugated plate fabricating machine combines advanced roll-forming technology with user-friendly controls, guaranteeing precise corrugation depth and panel flatness. Likewise, our storage silo corrugated panel machine is built for heavy-duty, high-volume production, ensuring long-term operational reliability in demanding manufacturing environments.

Complete Integrated Production Lines

For manufacturers seeking a turnkey solution, BenThomas provides a complete grain bin silo side body wall roll forming line. This integrated system streamlines the entire production process, from coil feeding and roll-forming through to cutting and stacking. By combining a grain bin silo sidewall roll bending machine with a grain bin silo corrugated panel production machine in a synchronized line, we maximize output, minimize labor, and ensure consistent quality across all produced components.

Why Partner with BenThomas?

Choosing BenThomas means investing in more than just machinery; it’s a partnership for growth. Our engineers work closely with clients to tailor each silo corrugated panel production machine or grain bin corrugated plate fabricating machine to specific production goals. We are committed to innovation, durability, and providing comprehensive support, ensuring your storage silo corrugated panel machine or complete grain bin silo side body wall roll forming line delivers peak performance for years to come.

Upgrade your fabrication capabilities with industry-leading technology from BenThomas. Contact our team today to discuss your project requirements for a grain bin silo sidewall roll bending machine, a high-output grain bin silo corrugated panel production machine, or a fully automated grain bin silo side body wall roll forming line. Let us equip you to build the future of agricultural storage.

Frequently Asked Questions

Successful FAT of a Silo Wall Panel Line for Major Indian Manufacturer

Project Case Study: Successful FAT of a Silo Sidewall Production Line Major Indian Manufacturer

Client: A leading silo manufacturing company based in Pune, India
Supplier:BEN THOMAS Machinery Co., Ltd.
Project:Factory Acceptance Test (FAT) for a Fully-Automated Corrugated Silo Wall Panel Production Line
FAT Date:March 2024

1. Client Challenge & Project Objective
Our client,a prominent player in India’s agricultural and industrial storage sector, faced challenges in meeting the surging demand for large-diameter silos. Their existing fabrication process for curved wall panels was labor-intensive, slow, and resulted in inconsistent quality, affecting onsite assembly speed and final silo integrity. They commissioned BEN THOMAS to deliver a complete, automated solution that would guarantee high output, exceptional dimensional accuracy, and robust construction for long-term reliability.

2. The BEN THOMAS Solution
BEN THOMAS engineered a heavy-duty, PLC-controlled corrugation shaping line specifically for high-volume production of corrugated silo wall panels.

Key Line Features:

· High-Precision Corrugation Shaping Forming System: Equipped with hardened tooling to form precise, repeatable corrugation profiles from galvanized steel coils (1mm to 4mm thickness).
· Integrated Punching System: For simultaneous, accurate piercing of bolt holes, lugs, and ladder attachment points in a single pass.
· PLC-Driven Variable-Radius Curving Unit: A standout feature allowing automatic, seamless curvature of panels to various diameters (from 4m to 30m+) without manual adjustment or template changes.
· Automatic Length Measurement & Cutting: Ensured each panel was cut to exact length with ±1mm tolerance.
· Complete Auxiliary Package: Included heavy-duty decoiler, precision leveller, run-out conveyor, and automatic stacking system for finished panels.

3. The Factory Acceptance Test: A Rigorous Validation
A 6-member technical delegation from the client visited the BENTHOMAS factory for a comprehensive 4-day FAT.

· Phase 1: Technical Documentation & Static Inspection. The client’s engineers meticulously reviewed all mechanical drawings, electrical schematics, and component certifications. They inspected the line’s build quality, weld integrity, and major branded components (Siemens PLC, Schneider electrics, etc.).
· Phase 2: Dynamic Dry & Wet Run. The core of the FAT involved multiple production runs using client-provided material.
1. Dry Run: All safety functions, emergency stops, and automatic sequences were tested without material.
2. Wet Run with Target Materials: The line processed several coils at incremental speeds (up to 25 meters per minute). The client team performed real-time quality checks on randomly selected panels, verifying:
· Profile geometry and consistency.
· Hole pattern positioning accuracy.
· Panel length and curvature radius against their specific silo design files.
· Surface finish quality (no scratches or deformation).
· Phase 3: Training & Final Sign-off. BEN THOMAS engineers provided hands-on operational and maintenance training. After addressing all queries and a final review meeting, the client’s Project Manager officially signed the FAT Certificate, confirming the line fully met all contractual performance and quality specifications.

4. Results & Client Endorsement

· Proven Performance: The line exceeded the guaranteed output rate by 12%, achieving a stable production speed of 28 m/min for standard panels.
· Unmatched Accuracy: All dimensional checks confirmed tolerance levels superior to industry standards, ensuring leak-proof, fast onsite assembly.
· Seamless Integration: The line’s PLC interface was praised for its user-friendliness, allowing quick changeovers between different panel specifications.

Client Feedback:
“The BEN THOMAS team demonstrated profound expertise and a cooperative spirit throughout the FAT. The line’s performance, particularly the accuracy of the automatic curving unit, has convinced us of its capability to revolutionize our production efficiency. This investment is a strategic move to enhance our market leadership, and we are confident in the long-term partnership with BEN THOMAS.”
— Director of Operations, Client Company

5. Conclusion
This successful FAT for a major Indian manufacturer underscores BEN THOMAS’s capability to deliver world-class, tailor-made industrial solutions. We combine robust engineering with transparent validation processes, ensuring our clients receive a production asset that is verified, reliable, and ready to deliver a rapid return on investment.

—

About BEN THOMAS
BEN THOMAS is a leading designer and manufacturer of high-performance roll forming systems and complete production lines for the global storage and construction industries. With decades of engineering excellence, we provide turnkey solutions that empower manufacturers to achieve superior quality, efficiency, and growth.

Upgrade Your Manufacturing Capability. Contact BEN THOMAS today to discuss your project requirements and schedule a visit to our demonstration facility.
